Product Description

APPLICATIONS

Drum reeling cable for use under high mechanical stresses, torsion, tension and torque. Suitable as vertical drum reeling cable under moderate mechanical stresses. A strength member has been integrated to increase tensile load, acceleration and speed. PUR sheath offers protection against hydrolysis, solvents, alkalines and oils.

CHARACTERISTICS

Voltage Rating (Uo/U) :         0.6/1kV

Temperature Rating :          Fixed installation: -50°C to +90°C

Mobile operation: -40°C to +90°C

Minimum Bending Radius :     Fixed : 6 x Overall Diameter

Mobile: 8 x Overall Diameter

Maximum Tensile Load :       20 N/mm2

Maximum Torsion :           +/- 25o/m

Travel Speed :                Festoon systems: up to 200m/min

Reeling applications: up to 200m/min horizontal

Minimum Distance for Change of Direction :  20x Overall Diameter

CONSTRUCTION

Conductor :     Class 5 flexible stranded Copper

Insulation :      LSZH (Low Smoke Zero Halogen)

Lay Up :        Central textile strength member, cores laid up in concentric layers

Inner Sheath :    PUR-HF (Polyurethane, halogen free flame retardant)

Braid :  Anti-twisting Textile braid

Outer Sheath :   PUR-HF (Polyurethane, halogen free flame retardant)

Core Identification :  4 Core: Green/Yellow Brown Black Grey

5 Core: Green/Yellow Blue Brown Black Grey

From 6 cores: white cores with black numbers

Sheath Colour :  Black or Yellow or Orange

STANDARDS

IEC 60228, DIN VDE 0293-308, IEC 60502 & VDE 0250, DIN VDE 0472-501, 502, 503, 508, DIN VDE 0472-401, 402, 602, 303, 615, DIN VDE 0250-1 and IEC 60502, IEC 60332-1

HD/EN/IEC 60811-2-1, DIN VDE 0473-811-2-1

ISO/IEC 17025 LABORATORY TESTED

This product is subject to the Quality Assurance protocols of The Cable Lab,

an ISO/IEC 17025 accredited cable testing laboratory. Testing includes vertical

flame, conductor resistance, tensile & elongation, and dimensional consistency,

verified to published standards and approved product drawings.
