2.5mm² Flat Twin and Earth Cable (Solid Copper, PVC)

2.5mm PVC Solid Copper House Wiring Electrical Cable Twin and Earth Flat Cable and Wire

Send Email Get Best Price

Key attributes

Industry-specific attributes

Application

Domestic wiring, light cable

Conductor Material

Copper

Conductor Type

Solid

Insulation Material

PVC

Other attributes

Place of Origin

Henan, China

Brand Name

JIANYUN

Model Number

BVVB

Type

insulated

rated voltage

450/750v 300/500V

cross section

0.5mm2-16mm2

cores

2 cores

price

direct factory price

standard

BS6004:2000丨IEC 60227丨GB/T 5023

Conductor Type

Solid

Sheath color

Grey

Product Description

2.5mm PVC Solid Copper House wiring electrical cable Twin and earth Flat cable and wire

6242y electric wire

CE certified PVC insulated flat cable, electric cable

electric pvc wire

1.Volt 300/500V 450/750V

2.Standars:

3.Certificate:ISO9001 CCC CE SABS

Electrical Wire Application: electric equipment, household, and electrical appliance

Solid or stranded copper conductor, PVC insulated
and PVC sheathed flat electrical wire (two cores or three cores)

The long term working temperature should lower then 70°C.

Flat Cables
Number of cores & Normal area mm2	Conductor Structure (main core) mm	Earth core structure mm	Aver.Thickness of insulation mm	Aver.Thickness of sheath mm	Approx. overall diameter mm
2x1.0+E	1x1.13	1x0.85	0.60	0.90	4.1x7.3
2x1.5+E	1x1.38	1x1.13	0.70	0.90	4.6x8.5
2x2.5+E	1x1.78	1x1.38	0.80	1.00	5.4x10.1
2x4.0+E	1x2.25	1x1.78	0.80	1.00	5.9x11.5
2x6.0+E	1x2.76	1x1.78	0.80	1.10	6.6x12.7

Industry-specific attributes
Application	Domestic wiring, light cable
Conductor Material	Copper
Conductor Type	Solid
Insulation Material	PVC
Other attributes
Place of Origin	Henan, China
Brand Name	JIANYUN
Model Number	BVVB
Type	insulated
rated voltage	450/750v 300/500V
cross section	0.5mm2-16mm2
cores	2 cores
price	direct factory price
standard	BS6004:2000丨IEC 60227丨GB/T 5023
Conductor Type	Solid
Sheath color	Grey
