Direct Factory Price Electric 12 Gauge Pvc Coated Electric Wire Sizes
|
Attribute |
Detail |
|
Product name |
N/A |
|
Brand Name |
JYXL |
|
Model Number |
BV, THW, H07V-U(K) |
|
Type |
insulated |
|
Application |
indoor, building, housing, lighting |
|
Usage |
indoor, housing, lighting |
|
Conductor |
single solid, stranded or flexible wire |
|
Conductor Material |
copper or aluminum |
|
Conductor Type |
single solid or stranded |
|
Insulation Material |
PVC |
|
Insulation |
pvc or thermoset plastic |
|
Size |
tw 12 electrical wire |
|
Certificate |
CE |
|
Standard |
IEC, BS, ASTM, DIN ect |
|
Price |
direct factory price |
|
Experience |
since 1993 |
|
R & D |
yes |
|
Place of Origin |
Henan, China |
Packaging and Delivery
|
Attribute |
Detail |
|
Selling Units |
Single item |
|
Packaging Details |
flexible package, carton, coil, wooden case for electric wire |
|
Port of dispatch |
Tianjin Qingdao or other main port |
|
Packing |
roll, carton, coil, wooden case |
Supply Capacity
Attribute
Detail
Supply Ability
10,000,000 meters per Month tw 12 electrical wire
Copper conductor/PVC insulation
1.Volt 600V
2.Standars:UL 83
3.Certificate:UL
electric equipment, household, and electrical appliance
Electric Wire working condition:
Conductor: Solid or strand annealed copper or CCA wire
Insulation: Polyvinyl Chloride (PVC 75° C ), flame retardant, Suitable for use in wet or dry locations
Electric wire standard:
ASTM B3, NTC 359. :Soft copper wire.
ASTM B8, NTC 307. :Concentric Lay Stranded copper conductors.
ASTM B787. 19 :Wire Combination Unilay Stranded Copper conductors for subsequent insulation
UL 1581, NTC-3203.: Reference Standard for Electrical Wires, Cables and Flexible Cords.
UL 83, NTC-1332. :Thermoplastic insulated Wires and Cables.
|
Item Spec. |
AWG SIZE |
No./Diameter of conductor |
Insulation thickness |
Max.outer diameter (mm) |
Ref .Weight(km/kg) |
|
THW-16B |
16 |
7/0.49 |
0.76 |
2.8 |
19 |
|
THW-14B |
14 |
7/0.62 |
0.76 |
3.4 |
29 |
|
THW-12B |
12 |
7/0.78 |
0.76 |
3.9 |
42 |
|
THW-10B |
10 |
7/0.98 |
0.76 |
4.5 |
62 |
|
THW-8B |
8 |
7/1.23 |
1.14 |
6 |
103 |
|
THW-6B |
6 |
7/1.56 |
1.52 |
7.8 |
169 |
|
THW-4B |
4 |
7/1.96 |
1.52 |
9 |
249 |
|
THW-3B |
3 |
7/2.20 |
1.52 |
9.7 |
306 |
|
THW-2B |
2 |
7/2.47 |
1.52 |
10.5 |
376 |
|
THW-1B |
1 |
19/1.68 |
2.03 |
12.5 |
487 |
|
THW-1/0B |
1/0 |
19/1.89 |
2.03 |
13.6 |
600 |
|
THW-2/0B |
2/0 |
19/2.12 |
2.03 |
14.7 |
739 |
|
THW-3/0B |
3/0 |
19/2.38 |
2.03 |
16 |
912 |
|
THW-4/0B |
4/0 |
19/2.67 |
2.03 |
17.5 |
1130 |
|
THW-16A |
16 |
1/1.29 |
0.76 |
2.9 |
19 |
|
THW-14A |
14 |
1/1.63 |
0.76 |
3.2 |
27 |
|
THW-12A |
12 |
1/2.05 |
0.76 |
3.6 |
39 |
|
THW-10A |
10 |
1/2.59 |
0.76 |
4.1 |
59 |
|
THW-8A |
8 |
1/3.26 |
1.14 |
5.6 |
98 |
