Home / Product / Electric Wire / UL 1277 Type TC-ER/LS 2/0 AWG LSZH Cable
U L 1277 Type TC-ER/LS 2/0AWG LSZH Sheath Cable Price List in USA and Samples USA
|
Attribute |
Detail |
|
Model Number |
LSZH cable |
|
Brand Name |
JYXL |
|
Type |
LOW VOLTAGE |
|
Application |
Industrial |
|
Conductor Material |
Copper |
|
Insulation Material |
XLPE/PVC/LSZH |
|
Jacket |
LSZH |
|
Jacket materials |
LSZH |
|
Filler |
HFFR (Halogen free flame retardant) |
|
Voltage Rating Uo/U |
0.6/1kv to 36KV |
|
Temperature Rating |
-40°C to 250°C |
|
Minimum Bending Radius |
15 x overall diameter |
|
Flame retardant |
IEC 60332-1 |
|
STANDARDS |
IEC 60502, ASTM, BS 6724, BS EN/IEC 61034 |
|
Applications |
smoke emission and toxic fumes could pose a risk to human health |
|
Suit for |
Power cables, control cables, instrument cables, etc. |
|
Place of Origin |
Henan, China |
Packaging and Delivery
|
Attribute |
Detail |
|
Selling Units |
Single item |
|
Packaging Details |
Rolls or drums |
|
Port of dispatch |
Tianjin Qingdao or other main port |
|
Packaging examples |
Image provided |
Supply Capacity
|
Attribute |
Detail |
|
Supply Ability |
500,000 kiloamperes per Month |
Three or four bare stranded copper conductors
insulated with PVC/nylon cabled with applicably sized bare copper
ground wire with overall PVC jacket
Temperature Rating: 90C wet, 75C dry
Conductor Size Range: 12 AWG to 500 kcmil
UL Listed as 600 V Type TC-ER per UL 1277 • Conductors listed as THHN/THWN per UL 83 • Meets
flame testing requirements of UL 1685 and IEEE 1202/CSA FT4
Marked direct burial and sunlight-resistant • RoHS Compliant
|
CONDUCTOR SIZE (STRANDING) |
NUMBER OF conductor |
GROUND WIRE SIZE (AWG) |
NOMINAL INSULATION (MILS) |
NOMINAL JACKET THICKNESS |
APPROX. O.D. (INCHES) |
|
12 (7W) |
3 |
14 |
20 |
45 |
0.385 |
|
10 (7W) |
3 |
12 |
20 |
45 |
0.45 |
|
8 (7W) |
3 |
10 |
36 |
60 |
0.6 |
|
6 (7W) |
3 |
8 |
36 |
60 |
0.69 |
|
4 (7W) |
3 |
8 |
48 |
80 |
0.875 |
|
2 (7W) |
3 |
6 |
48 |
80 |
1 |
