250ft THWN/THHN Electrical Wire Roll

PVC Insulated Thwn/Thhn Awg Size 14 12 10 8 6 4 2 Electrical Wire Feet Price 250ft Per Roll Distributor/wholesaler Price

Send Email Get Best Price

Details

Key Attributes

Attribute	Detail
Model Number	THHN
Brand Name	JYXL
Type	insulated
Usage	Building use
Application	Heating
Conductor Material	Copper
Conductor Type	Stranded
Number of core	single, 1
Insulation Material	PVC
Jacket	Nylon
Working temperature	-40~+90°C
Voltage	600V
Section	14AWG-500MCM
Popular section	14AWG, 12AWG, 10AWG, 8AWG, 2AWG
Standard	UL83
UL listed	Yes
Use for	AC, MC, NM-B cable inner core
Place of Origin	Henan, China

Packaging and Delivery

Attribute	Detail
Selling Units	Single item
Packaging Details	Coil or drum
Single package size	1X0.5X1 cm
Single gross weight	0.200 kg
Port of dispatch	Tianjin Port, China
Packaging examples	Image provided

Supply Capacity

Attribute	Detail
Supply Ability	10,000,000 kilometers per Month

Product Description

THHN Building Wire is general purpose wiring in accordance with the NEC.
The building wire is rated at 600 volts for installat

THHN: Thermoplastic Insulation (usually PVC),
High Heat Resistant (90° C rating), dry locations only,
Nylon jacket. Also rated THWN.

THHN Building Wire is general purpose wiring in accordance with the NEC. The building wire is rated at 600 volts for installation in conduit or other recognized raceway. THHN Wire may also be used for wiring of machine tools, appliances and control circuits.

Building Wire - THHN Wire Description:
THHN Wire has a conductor of soft drawn bare copper.
THHN Wire has primary insulation of PVC with NYLON jacket.
UL listed Stds. 83 & 1063 as: Type THHN Wire 90° C in dry locations,
Type THWN Wire 75° C in wet locations.
Gasoline and oil resistant II. Type MTW 90° C Machine Tool Wire (stranded only) 105° C AWM, 80° C where exposed to oil.
approval available upon request for the building wire.
