Best Price Solar Power Cable

Best Price Single Core 2.5mm2 4mm2 6mm2 10mm2 DC Cable PV Solar Power Electrical Cable Wire

Send Email Get Best Price

Details

Key Attributes

Attribute	Detail
Product name	Solar Cable 6mm
Model Number	solar cable
Brand Name	JYXL
Application	Construction
Type	Low Voltage
Conductor Material	Copper
Conductor	tinned flexible copper wire
Insulation Material	XLPE
Insulation	XLPO
Jacket	NO
Sheathed	XLPO
Cross-section	1.5mm², 2.5mm², 4.0mm², 6.0mm², 10mm², 16mm²
Voltage	DC1500V
Characteristic	High Heat Water Resistant
Standard	EN50618
Certificate	TUV certificate
Sample	Free
Place of Origin	Henan, China

Packaging and Delivery

Attribute	Detail
Selling Units	Single item
Packaging Details	Standard export drum for dc solar cable
Port of dispatch	Tianjin port, Qing dao port, Shang hai port

Supply Capacity

Attribute	Detail
Supply Ability	500 kilometers per Month DC solar cable

Product description

Applications:

This cable is used for interconnecting power supplies within renewable energy photovoltaic systems, such as solar panel arrays in solar energy farms. These solar panel cables are suitable for fixed installations, both internal and external, and within conduits or systems.

Structure:

1. Conductor: Tinned soft copper wires, class 5, according to EN60228;

2. Insulation: Cross-linked polyolefin, low smoke zero halogen(LSZH)

3. Jacket: Cross-linked polyolefin, low smoke zero halogen(LSZH)

Working temperature:

Max. conductor temperature: 120℃

Ambient temperature: -40 to +90.

Standards:

EN50618

Voltage:

DC 1.5KV, AC1.0/1.0KV

Performance:

Strong UV resistance

Flame retardant

Low smoke halogen free LSZH

Lift time at least 25 years

Test voltage:

AC 6.5KV for 5min, not break down

Size	Conductor Diameter	Insulation	Outer-sheath Thickness	Approx O.D.	Max. DC
Size	Conductor Diameter	Thickness	Outer-sheath Thickness	Approx O.D.	resistance at 20 C
mm2	mm	mm	mm	mm	Ω/km
1.5	0.25	0.7	0.8	4.6	13.7
2.5	0.25	0.7	0.8	5.0	8.21
4	0.30	0.7	0.8	5.6	5.09
6	0.30	0.7	0.8	6.3	3.39
10	0.40	0.7	0.8	7.4	1.95
16	0.40	0.7	0.9	8.6	1.24
25	0.40	0.9	1.0	11.1	0.795
35	0.40	0.9	1.1	13.0	0.565
50	0.40	1.0	1.2	15.1	0.393
70	0.50	1.1	1.2	17.2	0.277
95	0.50	1.1	1.3	18.6	0.210
120	0.50	1.2	1.3	20.6	0.164
150	0.50	1.4	1.4	23.4	0.132
185	0.50	1.6	1.6	25.5	0.108
240	0.50	1.7	1.7	28.7	0.0817
