14 AWG THHN/THWN Electrical Wire

14 AWG 600V Electrical Wires 90C 7 Wire Cable THHN THWN PVC-NYLON White Black Red Green Blue Yellow-600V Distributor

Send Email Get Best Price

Key Attributes

Attribute	Detail
Model Number	THHN THWN
Type	UL approved insulated cable
Brand Name	JYXL
Place of Origin	Henan, China
Voltage	600V
Conductor Material / Conductor	Copper or AL-8000
Conductor Type	Stranded or Solid
Stranding	ASTM B8
Insulation Material / Insulation	PVC or PVC/Nylon
Number of core	1
Section	Cu: over 14 AWG Al: over 8 AWG
Popular section	14 AWG,12 AWG,10 AWG,8 AWG,2 AWG,1/0,2/0,3/0,4/0,250MCM,300MCM
Working temperature	−40°C +90°C
Application / Usage	Buildings, wiring, Building use
Standard	UL83

Packaging and Delivery

Attribute	Detail
Selling Units	Single item

HHN or THWN-2 conductors are primarily used in conduit and cable trays for services, feeders,

and branch circuits in commercial or industrial applications as specified in the National Electrical Code.

Voltage for all applications is 600 volts.

When used as type THHN, conductor is suitable for use in dry locations at temperatures not to exceed 90°C.

When used as type THWN, conductor is suitable for use at temperatures not to exceed 90°C, dry locations

or 75°C wet locations or not to exceed 75°C when exposed to oil or coolant.

When used as type THWN-2, conductor is suitable for use in wet and dry locations at temperatures not to

exceed 90°C or not to exceed 75°C when exposed to oil or coolant.

THW wire– Indicates a single conductor having flame-retardant, moisture and heat-resistant thermoplastic insulation.

The wire is rated 75°C wet or dry.THW cable and wires are used generally in building wiring, feeder and branch circuits,

and internal secondary industrial distribution.

TW wire– Indicates a single conductor having flame-retardant, moisture-resistant thermoplastic insulation.

The wire is rated 60°C wet or dry.TW cable and wires are used generally in building wiring, feeder and branch circuits,

and internal secondary industrial distribution

Technical Compliances

- UL 83 - Thermoplastic-Insulated Wires and Cables

- CSA C22.2 No. 75-03

- UL 1063 (MTW) - Machine-Tool Wires and Cables (stranded

cables only)

- UL 758 (AWM)

- ICEA S-95-658/NEMA WC 70

Conductor: Soft annealed bare copper, Class B

stranding per ASTM B8

Insulation: Tough, heat and moisture resistant Polyvinyl chloride (PVC)

insulation over which a nylon jacket is applied.

Color:option
