Home / Product / Electric Wire / SAE J1127 SGX/SGT Automotive Wire
American Standard Automobile Wire SGX SGT for Car Wiring with SAE J1127 Standard
|
Attribute |
Detail |
|
Model Number |
SGT |
|
Product Name |
SGT cable |
|
Brand Name |
JYXL |
|
Type |
Insulated |
|
Core |
single core |
|
Conductor Material |
Copper |
|
Conductor Type |
flexible copper wire |
|
Conductor |
Flexible Tinned Copper |
|
Insulation Material |
PVC |
|
Sheathed |
PVC |
|
Application |
automotive and vehicular |
|
Standard |
SAE J1127 |
|
Voltage |
25V AC, 60V DC |
|
Size |
6AWG-4/0AWG |
|
Rated Temperature |
-50°C to 80°C |
|
Performance |
Resistant to battery acid, crushing force, diesel fuel |
|
Place of Origin |
Henan, China |
Packaging and Delivery
|
Attribute |
Detail |
|
Selling Units |
Single item |
|
Packaging Details |
soft packing, 500M/Roll |
|
Port of dispatch |
Tianjin port |
Supply Capacity
|
Attribute |
Detail |
|
Supply Ability |
50,000 kilometers per Month |
25V AC 60V DC 6awg 4awg 2AWG PVC jacketed flexible copper SGT battery cable with SAE J1127 Standard
Type SGT is a multi-purpose battery cable designed for use in automotive and vehicular applications (e.g. car, bus, truck, tractor, heavy equipment, etc.) as well as a variety of industrial environments. Type SGT is UL listed, meets SAE J1127requirements, compliant to RoHS standards.
Conductors:Rope-lay, bunch-stranded bare copper conductor
Voltage Rating:60 V DC; 25 V AC
Insulation & Jacket :Jacketed with PVC compound
Resistance Properties
Resistant to battery acid, crushing force, diesel fuel, engine coolant, engine oil, ethanol, extreme temperatures, flame, gasoline, power-steering fluid, and transmission fluid
Temperature Range:-50°C (-58°F) to 80°C (176°F)
UL 2556
Meets battery cable requirements per UL 558 and 583
SAE J1127 Compliant
REACH, RoHS, CMRT, and Prop 65 Compliant
|
AWG Size |
Stranding Gauge |
Conductor Stranding |
Wall Thickness |
Outside Diameter |
Cable Weight |
|||
|
(Nominal) |
(Nominal) |
(per 1,000') |
||||||
|
|
|
|
in |
mm |
in |
mm |
lbs |
kg |
|
#6 |
0.014 |
133 |
0.06 |
1.52 |
0.31 |
7.87 |
106 |
48 |
|
#4 |
0.017 |
133 |
0.065 |
1.65 |
0.38 |
9.65 |
161 |
73 |
|
#2 |
0.022 |
133 |
0.065 |
1.65 |
0.43 |
10.92 |
240 |
109 |
|
#1 |
0.024 |
133 |
0.065 |
1.65 |
0.47 |
11.94 |
293 |
133 |
|
1 / 0 |
0.027 |
133 |
0.065 |
1.65 |
0.535 |
13.59 |
374 |
170 |
|
2 / 0 |
0.031 |
133 |
0.065 |
1.65 |
0.56 |
14.22 |
446 |
202 |
|
3 / 0 |
0.021 |
361 |
0.078 |
1.98 |
0.621 |
15.77 |
564 |
255 |
|
4 / 0 |
0.024 |
361 |
0.078 |
1.98 |
0.677 |
17.2 |
708 |
321 |
