Single Core Aluminum Mobile Power Cable (1.8/3kV)

Single Core Aluminum Mobile Power Cable (1.8/3kV)

JYXL Brand Factory Price 1.8/3kV Medium Voltage Single Core Aluminum Conductor Manufacturer of Mobile Electric Power Cables

Send Email Get Best Price
  • Details

Key attributes

Industry-specific attributes

Insulation Material

xlpe

Application

Industrial

Conductor Material

Aluminum

Jacket

PVC

Other attributes

Place of Origin

Henan, China

Brand Name

JYXL

Model Number

YJV22

Type

Medium Voltage

Size

25mm 50mm 75mm

Product name

Power Cable

Rated voltage

1.8/3kV

YJV22

XLPE insulated steel armoured PVC sheathed power cable

Conductor type

Aluminum

Color

Black Orange

Insulation

XLPE

Jacket

PVC Jacket

Core

Single Core

Certificate

GB/T12706-2008

Application

Power Transmission

PRODUCT SHOW



Aluminum Conductor Single Core XLPE Insulated Unarmoured Power Cable

Construction

Conductors
Plain aluminium or aluminium alloy in accordance with IEC 60228.

Insulation
XLPE material and thickness shall be as per IEC 60502 or BS 5467 rated for 90°C continuous operation.

Outer Sheath

Outer sheath shall be of extruded PVC Type ST1/ST2 as per IEC 60502-1

Application

These cables are used for electricity supply in low voltage installation system, They are suitable for installation in indoors and outdoors, in cable ducts, under ground, in power and switching stations, local energy distributions, industrial plants, where there is no risk of mechanical damage.

Nominal Cross Section

Diameter of Conductor (Approx.)

Nominal Insulation Thickness

Nominal Sheath Thickness

Overall Diameter (Approx.)

mm^2

mm

mm

mm

mm

1x1.5

1.4

0.7

1.4

5.6

1x2.5

1.8

0.7

1.4

6

1x4

2.3

0.7

1.4

6.5

1x6

2.8

0.7

1.4

7

1x10

3.6

0.7

1.4

7.8

1x16

4.5

0.7

1.4

8.7

1x25

5.6

0.9

1.4

10.2

1x35

6.7

0.9

1.4

11.3

1x50

8

1

1.4

12.8

1x70

9.4

1.1

1.4

14.4

1x95

11

1.1

1.5

16.1

1x120

12.4

1.2

1.5

17.8

1x150

13.8

1.4

1.6

19.8

1x185

15.3

1.6

1.6

21.8

1x240

17.5

1.7

1.7

24.4

1x300

19.5

1.8

1.8

26.7

1x400

22.6

2

1.9

30.5

1x500

25.2

2.2

2

33.7

1x630

28.3

2.4

2.2

37.4

1x800

31.9

2.6

2.3

41.7

1x1000

35.7

2.8

2.4

46.2
