Low Voltage Power Cable
Low Voltage Power Cable

Low voltage power cables are used to transmit electrical power at voltages typically up to 1,000 volts (1 kV). These cables are widely used in residential, commercial, and industrial settings for a variety of applications, including power distribution, lighting, and control systems.

Home / Product / Low Voltage Power Cable / JYXL 4/5 Core Unarmored Cable (Cu/XLPE) 25-70mm² for SE Asia

JYXL 4/5 Core Unarmored Cable (Cu/XLPE) 25-70mm² for SE Asia

JYXL 4/5 Core Unarmored Cable (Cu/XLPE) 25-70mm² for SE Asia

JYXL Brand Copper Conductor 5 Core 4 Cores XLPE Insulated Unarmored 25mm 35mm 50mm 70mm Power Cable Southeast Asia Markets

Send Email Get Best Price
  • Details

Key attributes

Industry-specific attributes

Insulation Material

xlpe

Application

Industrial

Conductor Material

Copper

Jacket

PVC

Other attributes

Place of Origin

Henan, China

Brand Name

JYXL

Model Number

YJV

Type

LOW VOLTAGE

Size

5 CORE

Product name

0.6/1kV 5 Cores XLPE Insulated PVC Sheathed Unarmoured Copper Cable

Standard

GB12706, IEC60502

Conductor

Pure Copper

Voltage

0.6/1kV

Color

Black

Insulation

XLPE

Certificate

IEC

Core

4/5 CORE

Application

Power Transmission

Package

Wooden Durm







PRODUCT DETAIL

Low Voltage 0.6/1KV 5 Core Underground Copper Conductor Unarmored Power Electric Cable

Construction

Conductors
The conductors shall be either of Class 1 or Class 2 of plain or metal-coated annealed copper in accordance with IEC 60228.

Insulation
XLPE material and thickness shall be as per IEC 60502 or BS 5467 rated for 90°C continuous operation.

Outer Sheath

Outer sheath shall be of extruded PVC Type ST1/ST2 as per IEC 60502-1

Application

These cables are used for electricity supply in low voltage installation system, They are suitable for installation in indoors and outdoors, in cable ducts, under ground, in power and switching stations, local energy distributions, industrial plants, where there is no risk of mechanical damage.

Product Paramenters

No. of cores and nominal cross section

Thickness of Insulation

Thickness of Sheath

Approx. overall Diameter

Approx. weight

Max. DC resistance of conductor（20℃）

Current carrying capacity

(mm2)

(mm)

(mm)

(mm)

(kg/km)

(Ω/km)

In Air(A)

In Ground(A)

5X1.5

0.7

1.8

11.7

170

12.1

21

30

5X2.5

0.7

1.8

12.8

250

7.41

28

39

5X4

0.7

1.8

14

330

4.61

37

51

5X6

0.7

1.8

15.4

460

3.08

47

64

5X10

0.7

1.8

18.8

700

1.83

65

86

5X16

0.7

1.8

21.8

1000

1.15

84

110

5X25

0.9

1.8

26.2

1540

0.727

110

140

5X35

0.9

1.8

28

2080

0.524

135

170

5X50

1

1.9

32.4

2760

0.387

170

205

5X70

1.1

2.1

37.4

3890

0.268

215

250

5X95

1.1

2.2

41.7

5120

0.193

265

300

5X120

1.2

2.4

46.2

6530

0.153

310

345

5X150

1.4

2.6

53.1

8000

0.124

350

385

5X185

1.6

2.8

58.9

9800

0.0991

405

435

5X240

1.7

3

65.6

12400

0.0754

480

500

5X300

1.8

3.2

72

15450

0.0601

555

565
