TUV H1Z2Z2-K Solar Power Cable (25mm²)

TUV EN50618 Black 25mm2 H1Z2Z2-K Solar Cable 200m/reel Solar Cabled Power Cables Manufacturer in China

Send Email Get Best Price

Key Attributes

Attribute	Detail
Product Name	Photovoltaic Wire Solar Cable (PV Solar Cable)
Model Number	PV Solar Cable
Common Type	H1Z2Z2-K
Type	Low Voltage
Application	Photovoltaic (PV) Solar Power
Place of Origin	Henan, China
Brand Name	JYXL
Conductor Material	Copper/Aluminum/Tinned Copper
Conductor	Flexible Tinned Copper, Bare Copper, Aluminum alloy Conductor
Number of Cores	Single Core or Double Core
Insulation Material	XLPO (Cross-Linked Polyolefin)
Jacket	XLPO
Common Structure	CU(AL)/XLPO, CU(AL)/XLPO/XLPO
Voltage	AC 0.6/1 kV, DC 0.9/1.5kV, Max. 1.8 kV DC
Standard	EN50618 & TUV 2PfG/1169
Certificate	U L, TUV Double certification

Packaging and Delivery

Attribute	Detail
Selling Units	Single item
Packaging Details	Packing in wooden drum or According to customer demand
Port of Dispatch	Tianjin port, Qingdao port, Shanghai port or other port

Supply Capacity

Attribute	Detail
Supply Ability	10,000 kilometers per Month (photovoltaic wire cable)

This cable is used for interconnecting power supplies within renewable energy photovoltaic

systems, such as solar panel arrays in solar energy farms. These solar panel cables are suitable

for fixed installations, both internal and external, and within conduits or systems.

1. Conductor: Tinned soft copper wires, class 5, according to EN60228;

2. Insulation: Cross-linked polyolefin, low smoke zero halogen(LSZH)

3. Jacket: Cross-linked polyolefin, low smoke zero halogen(LSZH)

Max. conductor temperature: 120℃

Ambient temperature: -40 to +90.

EN50618

DC 1.5KV, AC1.0/1.0KV

Performance:

Strong UV resistanceFlame retardant

Low smoke halogen free LSZH

Lift time at least 25 years

AC 6.5KV for 5min, not break down

Conductor Size (mm2)	Inner Insulation	Outer Insulation	Approx. Nominal Overall Diameter
	Nominal Thickness	Nominal Thickness	Approx. Nominal Overall Diameter
	(mm)	(mm)	(mm)
1x4	0.7	0.8	5.6
1x6	0.7	0.8	6.3
1x10	0.7	0.8	7.4
1x16	0.7	0.9	8.6
1x25	0.9	1	11.1
1x35	0.9	1.1	13.0
1x50	1.0	1.2	15.1
1x70	1.1	1.2	17.2
1x95	1.1	1.3	18.6
1x120	1.2	1.3	20.6
1x150	1.4	1.4	23.4
1x185	1.6	1.6	25.5
1x240	1.7	1.7	28.7
