Solar cables are an essential component of solar photovoltaic (PV) systems, which convert sunlight into electricity. They are specifically designed to handle the demanding conditions found in solar installations, including exposure to UV rays, high temperatures, and moisture.
Home / Product / Solar Cable / Flexible Solar Cable for Power Stations
Original Factory DC1.8kV PV1-F 4mm Red Color Tinned Copper Single Core Solar Cable 6mm Photovoltaic Cable for Power Station
|
Attribute |
Detail |
|
Product Name |
DC1.8kV Solar Cable |
|
Model Number |
PV1-F |
|
Brand Name |
JianYun |
|
Type |
LOW VOLTAGE |
|
Application |
Industrial |
|
Core |
Single Core |
|
Conductor |
Tinned Copper |
|
Conductor Material |
Copper |
|
Insulation Material |
XLPO |
|
Jacket |
PVC |
|
Insulation |
XLPO Insulation |
|
Voltage |
0.6/1KV 1800V DC |
|
Rated Voltage |
0.6 kV |
|
Rated Current |
30A |
|
Color |
Black Red Orange |
|
Size |
1*6mm |
|
Hot Sale Size |
4mm/6mm Solar Cable |
|
Working Temperature |
90°C |
|
Material |
Tinned Copper+XLPO |
|
Standard |
GB50797-2012 |
|
MOQ |
1000m |
Packaging and Delivery
|
Attribute |
Detail |
|
Selling Units |
Single item |
Structure
1、tinned copper wire
2、halogen free insulation
3、halogen free sheath
|
No. Of cores x Construction |
Conductor |
Outer Diameter |
Resistance Max.(Ω/km) |
Current Aarring Capacity |
|
1*1.5 |
30/0.25 |
4.90 |
13.30 |
30 |
|
1.2.5 |
50/0.25 |
5.45 |
7.89 |
41 |
|
1*4 |
56/0.3 |
6.10 |
4.75 |
50 |
|
1.6 |
84/0.3 |
7.20 |
3.39 |
70 |
|
1*10 |
142/0.3 |
9.00 |
1.95 |
98 |
|
1*16 |
228/0.3 |
10.20 |
1.24 |
132 |
|
1*25 |
361/0.3 |
12.00 |
0.795 |
176 |
|
1*35 |
525/0.3 |
13.8 |
0.565 |
218 |
|
1*50 |
720/0.3 |
14.8 |
0.393 |
280 |
|
1*70 |
988/0.3 |
16.9 |
0.277 |
350 |
|
1*95 |
1349/0.3 |
18.7 |
0.21 |
410 |
|
1*120 |
1691/0.3 |
20.7 |
0.164 |
480 |
