1CX 400mm² Al Armoured XLPO 1.8kV SMB-Inverter Cable

1CX 400 Sqmm Al. Armoured XLPO 1.8KV Cable SMB to Inverter 9km Price 5% Discount for Distributor

Send Email Get Best Price

Details

Key Attributes

Attribute	Value
Model Number	RHH/RHW-2
Type	Low Voltage
Conductor Material	Aluminum
Conductor	Soft annealed copper Class B or Al 8000
Conductor Type	full compressed or unilay compressed
Core	Single Core
Insulation Material	XLPE
Insulation	XLPE 90 black
Jacket	XLPE
Feature	flame retardant
Application	Power Station
Certificate	U L 44/ RoHs
Brand Name	JYXL
Place of Origin	Henan, China

Packaging and Delivery

Attribute	Value
Packaging Details	Rolls or drums
Port of Dispatch	Tianjin, Qingdao or other main port
Selling Units	Single item

Product Description

Application

These cables are used for general purpose wiring in circuits not exceeding 2000 volts. May be used in wet or dry locations, installed in conduit, duct, open air.

Construction

Conductor: Soft annealed uncoated copper compressed, Class B stranding, or unilay compressed, per ASTM B8. Sizes: 14 AWG – 1000 kcmil. The aluminium-8000 series also can be used.

Insulation: Black Thermosetting flame retardant cross-linked polyethylene (XLPE)

Standards:

UL 44 Thermoset-Insulated Wire and Cable

Maximum operating voltage: RHH/RHW-2 up to 2000 volts

Maximum conductor operation temperatures: • 90 °C wet and dry

Section (AWG or MCM)	Number of strands	Insulation thickness (mils)	Approximate OD (inch)
14	7	60	0.20
12	7	60	0.22
10	7	60	0.24
8	7	70	0.29
6	7	70	0.33
4	7	70	0.37
2	7	70	0.43
1	19	90	0.52
1/0	19	90	0.56
2/0	19	90	0.60
3/0	19	90	0.65
4/0	19	90	0.71
250	37	105	0.78
350	37	105	0.89
500	37	105	1.01
