ACSR 795 MCM Bare Conductor

Code Name

Area

Stranding

Appro.

and

Overall

Diameter

Diameter

Aluminum

Steel

Total

Aluminum

Steel

AWG or

mm 2

mm 2

mm 2

mm

mm

mm

MCM

Wren

8

8.34

1.39

9.73

6/1.33

1/1.33

3.99

Turkey

6

13.29

2.19

15.48

6/1.68

1/1.68

5.04

Swan

4

21.16

3.55

24.71

6/2.12

1/2.12

6.36

Swante

4

21.16

5.35

26.5

7/1.96

1/2.61

6.53

Swallow

3

26.69

4.45

31.14

6/2.38

1/2.38

7.14

Sparrow

2

33.61

5.61

39.22

6/2.67

1/2.67

8.01

Sparate

2

33.61

8.52

42.13

7/2.47

1/3.30

8.24

Robin

1

42.39

7.1

49.49

6/3.00

1/3.00

9

Raven

0

53.48

8.9

62.38

6/3.37

1/3.37

10.11

Quail

2/0

67.42

11.23

78.65

6/3.78

1/3.78

11.34

Pigeon

3/0

85.03

14.19

99.22

6/4.25

1/4.25

12.75

Penguin

4/0

107.23

17.87

125.1

6/4.77

1/4.77

14.31

Waxwing

266.8

135.16

7.48

142.64

18/3.09

1/3.09

15.45

Partridge

266.8

135.16

22

157.16

26/2.57

7/2.00

16.28

Ostrich

300

152

24.71

176.71

26/2.73

7/2.12

17.28

Merlin

336.4

170.45

9.48

179.93

18/3.47

1/3.47

17.35

Linnet

336.4

170.45

27.81

198.26

26/2.89

7/2.25

18.31

Oriole

336.4

170.45

39.81

210.26

30/2.69

7/2.69

18.83

Chickadee

397.5

201.42

11. 16

212.58

18/3.77

1/3.77

18.85

Brant

397.5

201.42

26.13

227.55

24/3.27

7/2.18

19.61

Ibis

397.5

201.42

32.77

234.19

26/3.14

7/2.44

19.88

Lark

397.5

201.42

46.97

248.39

30/2.92

7/2.92

20.44

Pelican

477

241.68

13.42

255.1

18/4.12

1/4.14

20.7

Flicker

477

241.68

31.29

272.97

24/3.58

7/2.39

21.49

Hawk

477

241.68

39.42

281.1

26/3.44

7/2.67

21.79

Hen

477

241.68

56.39

298.07

30/3.20

7/3.20

22.4

Osprey

556.5

282

15.68

297.68

18/4.47

1/4.47

22.35

Parakeet

556.5

282

36.58

318.58

24/3.87

7/2.58

23.22

Dove

556.5

282

45.94

327.94

26/3.72

7/2.89

23.55

Eagle

556.5

282

65.81

347.81

30/3.46

7/3.46

24.21

Peacock

605

306.58

39.74

346.32

24/4.03

7/2.69

24.2

Squab

605

306.58

49.94

356.52

26/3.87

7/3.01

24.51

Wood duck

605

306.58

71.55

378.13

30/3.16

7/3.61

25.25

Teal

605

306.58

69.87

376.45

30/3.61

19/2.16

25.24

Kingbird

636

322.26

17.9

340.16

18/4.78

1/4.78

23.88

Rook

636

322.26

41.81

364.07

24/4.14

7/2.76

24.84

Grosbeak

636

322.26

52.45

374.71

26/3.97

7/3.09

25.15

Scoter

636

322.26

75.22

394.48

30/3.70

7/3.70

25.88

Egret

636

322.26

73.55

395.81

30/3.70

19/2.22

25.9

Swift

636

322.26

8.96

331.22

36/3.38

1/3.38

23.62

Flamingo

666.6

337.74

43.81

381.55

24/4.23

7/2.82

25.4

Gannet

666.6

337.74

55.03

392.77

26/4.07

7/3.16

25.76

Stilt

715.5

362.58

46.97

409.55

24/4.39

7/2.92

26.31

Starling

715.5

362.58

59.03

421.61

26/4.21

7/3.28

26.68

Redwing

715.5

362.58

82.58

445.16

30/3.92

19/2.35

27.43

Tern

795

402.84

27.87

430.71

45/3.38

7/2.25

27.03

Condor

795

402.84

52.19

455.03

54/3.08

7/3.08

27.72

Cuckoo

795

402.84

52.19

455.03

24/4.62

7/3.08

27.74

Drake

795

402.84

65.51

468.45

26/4.44

7/3.45

28.11

Coot

795

402.84

11.16

414

36/3.77

1/3.77

26.41

Mallard

795

402.84

91.87

484.71

30/4.14

19/2.48

28.96

Ruddy

900

456.06

31.54

487.6

45/3.59

7/2.40

28.73

Canary

900

456.06

59.1

515.16

54/3.28

7/3.28

29.52

Rail

954

483.42

33.42

516.84

45/3.70

7/2.47

29.61

Catbird

954

483.42

13.42

496. 84

36/4.14

1/4.14

28.95

Cardinal

954

483.42

62.65

546. 07

54/3.38

7/3.38

30.42

Ortolan

1033.5

523.68

36.19

559. 87

45/3.85

7/2.57

30.81

Tanager

1033.5

523.68

14.51

538.19

36/4.30

1/4.30

30.12

Curlew

1033.5

523.68

67.87

591.55

54/3.52

7/3.52

31.68

Bluejay

1113

563.93

39.03

602.96

45/4.00

7/2.66

31.98

Finch.

1113

563.93

71.55

635.48

54/3.65

19/2.19

32.85

Bunting

1192.5

604.26

41.55

645.81

48/4.14

7/2.76

33.12

Grackle

1192.5

604.26

76.58

680.84

54/3.77

19/2.27

33.97

Bittern

1272

644.51

44.52

689.03

45/4.27

7/2.85

34.17

Pheasant

1272

644.51

81.63

726.19

54/3.90

19/2.34

35.1

Skylark

1272

644.51

17.87

662.38

36/4.78

1/4.78

33.42

Dipper

1351.5

684.84

47.1

731.94

45/4.40

7/2.92

35.16

Martin

1351.5

684.84

88.71

771.55

54/4.02

19/2.41

36.17

Bobolink

1431

725.1

50.32

775.42

45/4.53

7/3.02

36.24

Plover

1431

725.1

91.87

816.97

54/4.14

19/2.48

37.24

Nuthatch

1510.5

765.35

52.9

818.25

45/4.65

7/3.10

37.2

Parrot

1510.5

765.35

96.84

862.19

54/4.25

19/2.55

38.25

Lapwing

1590

805.68

55.48

861.16

45/4.77

7/3.18

38.16

Falcon

1590

805.68

102.1

907.81

54/4.36

19/2.62

39.26

Chukar

1780

902.7

73.51

902.72

84/3.70

19/2.22

40.7

BlueBird

2156

1092

88.8

1092.28

84/4.07

19/2.44

44.76

Kiwi

2167

1100

47.5

1099.2

72/4.41

7/2.94

44.07

Thrasher

2312

1170.8

65.15

1170.8

76/4.43

19/2.09

45.9

Grouse

80

40.52

14.13

54.65

8/2.54

1/4.24

9.32

Petrel

101.8

51.61

30.06

81.67

12/2.34

7/2.34

11.71

Minorca

110.8

56.13

32.77

88.9

12/2.44

7/2.44

12.22

Leghorn

134.6

68.19

39.81

108

12/2.69

7/2.69

13.46

Guinea

159

80.58

46.97

127.55

12/2.92

7/2.92

14.63

Dotterel

176.9

89.48

52.19

141.67

12/3.08

7/3.08

15.42

Dorking

190.8

96.71

56.39

153.1

12/3.20

7/3.20

16.03

Brahma

203.2

102.97

91.87

194.84

16/2.86

19/2.48

18.14

Cochin

211.3

107.1

62.45

169.55

12/3.37

7/3.37

16.84
