HV ACSR Bare Conductor 120/20

Overhead Line ACSR Bare Conductor High Voltage ACSR Conductor 120/20

Send Email Get Best Price

Details

Key Attributes

Attribute	Detail
Product Name	Aluminum Conductor Steel Reinforced ACSR Conductor 120/20
Brand Name	JYXL
Model Number	ACSR conductor-DIN 48204 Standard
Type	Overhead
Application	Construction
Conductor	Aluminum Conductor Steel Reinforced
Conductor Material	Aluminum
Insulation Material	/ (Not insulated)
Jacket	Non-sheathing Bare
Usage	Overhead Transmission Lines
Standard	BS EN 50182, IEC 61089, ASTM B 232, DIN 48204, GB/T 1179, AS3607
Certificate	IEC
Place of Origin	Henan, China
MOQ	1000
Package	Wooden Drum
Service	ODM OEM Accepted

Packaging and Delivery

Attribute	Detail
Selling Units	Single item

PRODUCT SHOW

Aluminum Conductor Steel reinforced ACSR Conductor 120/20

ACSR Conductor Description:

ACSR has simple structure, convenient installation and maintenance, low budget cost, large transmission capacity, and is conducive to the laying of special geographical conditions such as crossing rivers and valleys . It has good electrical conductivity and sufficient mechanical strength, high tensile strength etc. Therefore, it is widely used in overhead transmission and distribution lines of various voltage levels.

ACSR Conductor Conductor Section:

Application:

Suitable for transmission lines of different voltage levels. It can also be laid in rivers, canyons and places with special geographical features. Aluminum Conductor Steel reinforced ACSR Conductor 120/20 Characteristics: 1. Simple structure, easy installation and maintenance, low line cost, large transmission capacity 2. Excellent conductivity 3. The cable has an overall high tensile strength

Product Paramenters

ACSR Conductor DIN 48204 Standard

Area				Standing and		Overall
				Wire Diameter		Diameter

Nominal.	Actual					Total.
Al/Steel	Al	Steel	Total	Aluminum	Steel	Total.
Al/Steel	mm 2	mm 2	mm 2	mm	mm	mm	kg/km
16/2.5	15	2.5	17.8	6/1.80	1/1.80	5.4	62
25/4.0	23.8	4	27.8	6/2.25	1/2.5	6.8	97
35/6.0	34.3	5.7	40	6/2.70	1/2.70	8.1	140
44/32.0	44	31.7	75.7	14/2.00	7/2.40	11.2	372
50/8.0	48.3	8	56.3	6/3.20	1/3.20	9.6	196
50/30	51.2	29.8	81	12/2.33	7/2.33	11.7	378
25903	69.9	11.4	81.3	26/1.85	7/1.44	11.7	284
95/15	94.4	15.3	109.7	26/2.15	7/1.67	13.6	383
95/55	96.5	56.3	152.8	12/3.20	7/3.20	16	712
105/75	105.7	75.5	181.5	14/3.10	9/2.25	17.5	891
120/20	121.06	19.8	141.4	26/2.44	7/1.90	15.5	494
120/70	122	71.3	193.3	12/3.60	7/3.60	18	90
125/30	127.9	29.8	157.7	30/2.33	7/2.33	16.3	591
150/25	148.9	24.2	173.1	26/2.70	7/2.10	17.1	605
170/40	171.8	40.1	211.9	30/2.70	7/2.70	18.9	794
185/30	183.8	29.8	213.6	26/3.00	7/2.33	19	746
210/35	209.1	34.1	243.2	26/3.20	7/2.49	20.3	850
210/50	212.1	49.5	261.6	30/3.00	7/3.00	21	981
230/30	230.9	29.8	260.7	24/3.50	7/2.33	21	877
240/40	243	39.5	282.5	26/3.45	7/2.68	21.9	987
265/35	263.7	34.1	297.8	24/3.74	7/2.49	22.4	1002
300/50	304.3	49.5	353.7	26/3.86	7/3.00	24.5	1236
305/40	304.6	39.5	344.1	54/2.68	7/2.68	24.1	1160
340/30	339.3	29.8	369.1	48/3.00	7/2.33	25	1180
380/50	382	49.5	431.5	54/3.00	7/3.00	27	1453
385/35	386	34.1	420.1	48/3.20	7/2.49	26.7	1344
435/55	434.03	59.3	490.6	54/3.20	7/3.20	28.8	1653
450/40	448.7	39.5	488.2	48/3.45	7/2.68	28.7	1561
490/65	490.3	63.6	553.9	54/3.40	7/3.40	30.6	1866
495/35	494.1	34.1	528.2	45/3.74	7/2.49	29.9	1646
510/45	510.2	45.3	555.5	48/3.68	7/2.87	30.7	1778
550/70	550	71.3	621.3	54/3.60	7/3.60	32.4	2092
560/50	561.7	49.5	611.2	48/3.86	7/3.00	32.2	1954
570/40	565.5	39.5	610.3	45/4.00	7/2.68	32.2	1888
650/45	698.5	45.3	653.49	45/4.30	7/2.87	34.4	2163
680/85	678.8	86	764.8	54/4.00	19/2.40	36	2570
1045/45	1045.58	45.3	1090.9	72/4.30	7/2.87	43	3249
