CE Flexible Electrical Wire (1.5mm² - 3.5mm²)

CE Certification Cable Flexible Electrical Cable Wire 1.5mm 2.5mm 3.5mm Electrical Wiring Cable

Send Email Get Best Price

Details

Key Attributes:

Attribute	Value	Category
Model Number	H07V-U, H07V-R, H07V-K	Identification/Standard
Type	Insulated	Configuration
Conductor Material	Copper	Construction
Conductor Type	Solid (Implied for -U, others for -R, -K)	Construction
Insulation Material	PVC	Construction
Nominal Voltage	$450/750\text{V}$	Electrical Rating
Rated Voltage	As Your Requirements	Electrical Rating
Application	INDOOR	Function
Service Temperature	$70^\circ\text{C}$	Environmental
Character	LOSH (Low Smoke Halogen?), FR (Flame Retardant)	Protection
Cores	1, 2, 3	Configuration
Cross Section	$0.75 - 240\text{ mm}^2$	Size/Configuration
Standars	IEC 60227	Compliance
Certificate	ISO9001, CCC, CE, SABS	Compliance
Color	as your request	Customization
Brand Name	JYXL	Logistics
Place of Origin	Henan, China	Logistics
Supply Ability	$1,000,000$ meters per Week	Commercial
Port of Dispatch	Tianjin port, Shanghai port, Qingdao port or others	Logistics
Selling Units	Single item	Commercial
Price/Sample	low price / free sample available	Commercial

Product descriptions

single core cable with CE certificate

1). multi strand wire Rated voltage U0/U 300/500V and 450/750V.

2). The long-time permissible temperature of cable: BV-105 below 105°C,and the other below 70°C.

3). Conductor maximum short circuit(not more than 5 seconds)temperature shall not be higher than 160°c.

4). The power cable is not limited by drop in level when being laid, and the ambient temperature shall not be lower than 0°c.
5). The bend radius: the external diameter of cable <25mm, and the bend radius is above 4 times of the external diameter of

cable. And the other is above 6 times of the external diameter of cable.

6). Perfect chemical stability, resistant against acids, alkalis, grease and organic solvents, and flame.
7). Light weight, perfect bending properties, installed and maintained easily and conveniently.

8). Insulation sheath material and color: PVC in red, black, blue or any color as required.

9). Type: Single or twin cables with different colors Provides OEM according to requests of customer.

electric wire specification

Type	Name	Laying place and requirement	Long term working Temperature 0C
60227IEC01 05 BV BLV	Copper conductor PVC insulated wires Aluminum conductor PVC insulated wires	Fixed laid indoors Conduit etc.	70
60227IEC07 (BV-90)	Heat resistant copper conductor PVC insulated wire at 90 0C	Mainly be laid at the places of high temperature environment and can be laid indoors ,conduits.	90
BVR	Copper conductor PVC insulated flexible wires	Be for laying permanent place where flexible required.	70
60227IEC10 (BVV) BVV	Copper conductor PVC insulated PVC sheathed round wires	Fixed laid, fit for the places with high mechanical protection and moisture place, can be laid in the air or underground.	70
BLVV	Aluminum conductor PVC insulated PVC sheathed round wires
BVVB	Copper conductor PVC insulated PVC sheathed flat wires
BLVVB	Aluminum conductor PVC insulated PVC sheathed flat wires
60227IEC02(RV) 60227IEC06(RV)	Copper conductor PVC insulated flexible connector wire	Mainly used at middle and light style moving electronics, home appliances, power and lighting and the places where flexible required	70
60227IEC42(RVB)	Copper conductor PVC insulated flat flexible connector wire
RVS	Copper conductor PVC insulated flexible twisting connector wire
60227IEC52(RVV) 60227IEC53	Copper conductor PVC insulated PVC sheathed round flexible connector wire
60227IEC08 (RV-90)	Cu conductor heat resistant PVC insulated flexible connector wire at 900C	Mainly used at the places where heat resistance is required	90
