Home / Product / Bare Conductor / ACSR Bare Overhead Conductor - 1/0
Overhead Line ACSR Bare Conductor ACSR Conductor 1/0 for Overhead Applications
|
Attribute |
Detail |
|
Product Name |
Overhead Line ACSR Bare Conductor ACSR Conductor 1/0 |
|
Application |
Construction |
|
Usage |
Overhead Transmission Lines |
|
Conductor Material |
Aluminum |
|
Conductor |
Aluminum Conductor Steel Reinforced |
|
Insulation Material |
/ (Bare Conductor) |
|
Jacket |
/ (Non-sheathing Bare) |
|
Type |
overhead |
|
Place of Origin |
Henan, China |
|
Brand Name |
JYXL |
|
Model Number |
ACSR conductor-ASTM-B232 Standard |
|
Standard |
BS EN 50182, IEC 61089, ASTM B 232, DIN 48204, GB/T 1179, AS3607 |
|
Certificate |
IEC |
|
MOQ |
1000 |
|
Package |
Wooden Drum |
|
Service |
ODM OEM Accepted |
Packaging and Delivery
|
Attribute |
Detail |
|
Selling Units |
Single item |
Description:
ACSR has simple structure, convenient installation and maintenance, low budget cost, large transmission capacity, and is conducive to the laying of special geographical conditions such as crossing rivers and valleys . It has good electrical conductivity and sufficient mechanical strength, high tensile strength etc. Therefore, it is widely used in overhead transmission and distribution lines of various voltage levels.
Suitable for transmission lines of different voltage levels. It can also be laid in rivers, canyons and places with special geographical features. Overhead Line ACSR Bare Conductor ACSR Conductor 1/0 Characteristics: 1. Simple structure, easy installation and maintenance, low line cost, large transmission capacity 2. Excellent conductivity 3. The cable has an overall high tensile strength
ACSR Conductor ASTM-B232 Standard
|
Code Name |
Area |
Stranding |
Appro. |
||||
|
and |
Overall |
||||||
|
Diameter |
Diameter |
||||||
|
|
|
||||||
|
|
Aluminum |
Steel |
Total |
Aluminum |
Steel |
||
|
|
AWG or |
mm 2 |
mm 2 |
mm 2 |
mm |
mm |
mm |
|
MCM |
|||||||
|
Wren |
8 |
8.34 |
1.39 |
9.73 |
6/1.33 |
1/1.33 |
3.99 |
|
Turkey |
6 |
13.29 |
2.19 |
15.48 |
6/1.68 |
1/1.68 |
5.04 |
|
Swan |
4 |
21.16 |
3.55 |
24.71 |
6/2.12 |
1/2.12 |
6.36 |
|
Swante |
4 |
21.16 |
5.35 |
26.5 |
7/1.96 |
1/2.61 |
6.53 |
|
Swallow |
3 |
26.69 |
4.45 |
31.14 |
6/2.38 |
1/2.38 |
7.14 |
|
Sparrow |
2 |
33.61 |
5.61 |
39.22 |
6/2.67 |
1/2.67 |
8.01 |
|
Sparate |
2 |
33.61 |
8.52 |
42.13 |
7/2.47 |
1/3.30 |
8.24 |
|
Robin |
1 |
42.39 |
7.1 |
49.49 |
6/3.00 |
1/3.00 |
9 |
|
Raven |
0 |
53.48 |
8.9 |
62.38 |
6/3.37 |
1/3.37 |
10.11 |
|
Quail |
2/0 |
67.42 |
11.23 |
78.65 |
6/3.78 |
1/3.78 |
11.34 |
|
Pigeon |
3/0 |
85.03 |
14.19 |
99.22 |
6/4.25 |
1/4.25 |
12.75 |
|
Penguin |
4/0 |
107.23 |
17.87 |
125.1 |
6/4.77 |
1/4.77 |
14.31 |
|
Waxwing |
266.8 |
135.16 |
7.48 |
142.64 |
18/3.09 |
1/3.09 |
15.45 |
|
Partridge |
266.8 |
135.16 |
22 |
157.16 |
26/2.57 |
7/2.00 |
16.28 |
|
Ostrich |
300 |
152 |
24.71 |
176.71 |
26/2.73 |
7/2.12 |
17.28 |
|
Merlin |
336.4 |
170.45 |
9.48 |
179.93 |
18/3.47 |
1/3.47 |
17.35 |
|
Linnet |
336.4 |
170.45 |
27.81 |
198.26 |
26/2.89 |
7/2.25 |
18.31 |
|
Oriole |
336.4 |
170.45 |
39.81 |
210.26 |
30/2.69 |
7/2.69 |
18.83 |
|
Chickadee |
397.5 |
201.42 |
11. 16 |
212.58 |
18/3.77 |
1/3.77 |
18.85 |
|
Brant |
397.5 |
201.42 |
26.13 |
227.55 |
24/3.27 |
7/2.18 |
19.61 |
|
Ibis |
397.5 |
201.42 |
32.77 |
234.19 |
26/3.14 |
7/2.44 |
19.88 |
|
Lark |
397.5 |
201.42 |
46.97 |
248.39 |
30/2.92 |
7/2.92 |
20.44 |
|
Pelican |
477 |
241.68 |
13.42 |
255.1 |
18/4.12 |
1/4.14 |
20.7 |
|
Flicker |
477 |
241.68 |
31.29 |
272.97 |
24/3.58 |
7/2.39 |
21.49 |
|
Hawk |
477 |
241.68 |
39.42 |
281.1 |
26/3.44 |
7/2.67 |
21.79 |
|
Hen |
477 |
241.68 |
56.39 |
298.07 |
30/3.20 |
7/3.20 |
22.4 |
|
Osprey |
556.5 |
282 |
15.68 |
297.68 |
18/4.47 |
1/4.47 |
22.35 |
|
Parakeet |
556.5 |
282 |
36.58 |
318.58 |
24/3.87 |
7/2.58 |
23.22 |
|
Dove |
556.5 |
282 |
45.94 |
327.94 |
26/3.72 |
7/2.89 |
23.55 |
|
Eagle |
556.5 |
282 |
65.81 |
347.81 |
30/3.46 |
7/3.46 |
24.21 |
|
Peacock |
605 |
306.58 |
39.74 |
346.32 |
24/4.03 |
7/2.69 |
24.2 |
|
Squab |
605 |
306.58 |
49.94 |
356.52 |
26/3.87 |
7/3.01 |
24.51 |
|
Wood duck |
605 |
306.58 |
71.55 |
378.13 |
30/3.16 |
7/3.61 |
25.25 |
|
Teal |
605 |
306.58 |
69.87 |
376.45 |
30/3.61 |
19/2.16 |
25.24 |
|
Kingbird |
636 |
322.26 |
17.9 |
340.16 |
18/4.78 |
1/4.78 |
23.88 |
|
Rook |
636 |
322.26 |
41.81 |
364.07 |
24/4.14 |
7/2.76 |
24.84 |
|
Grosbeak |
636 |
322.26 |
52.45 |
374.71 |
26/3.97 |
7/3.09 |
25.15 |
|
Scoter |
636 |
322.26 |
75.22 |
394.48 |
30/3.70 |
7/3.70 |
25.88 |
|
Egret |
636 |
322.26 |
73.55 |
395.81 |
30/3.70 |
19/2.22 |
25.9 |
|
Swift |
636 |
322.26 |
8.96 |
331.22 |
36/3.38 |
1/3.38 |
23.62 |
|
Flamingo |
666.6 |
337.74 |
43.81 |
381.55 |
24/4.23 |
7/2.82 |
25.4 |
|
Gannet |
666.6 |
337.74 |
55.03 |
392.77 |
26/4.07 |
7/3.16 |
25.76 |
|
Stilt |
715.5 |
362.58 |
46.97 |
409.55 |
24/4.39 |
7/2.92 |
26.31 |
|
Starling |
715.5 |
362.58 |
59.03 |
421.61 |
26/4.21 |
7/3.28 |
26.68 |
|
Redwing |
715.5 |
362.58 |
82.58 |
445.16 |
30/3.92 |
19/2.35 |
27.43 |
|
Tern |
795 |
402.84 |
27.87 |
430.71 |
45/3.38 |
7/2.25 |
27.03 |
|
Condor |
795 |
402.84 |
52.19 |
455.03 |
54/3.08 |
7/3.08 |
27.72 |
|
Cuckoo |
795 |
402.84 |
52.19 |
455.03 |
24/4.62 |
7/3.08 |
27.74 |
|
Drake |
795 |
402.84 |
65.51 |
468.45 |
26/4.44 |
7/3.45 |
28.11 |
|
Coot |
795 |
402.84 |
11.16 |
414 |
36/3.77 |
1/3.77 |
26.41 |
|
Mallard |
795 |
402.84 |
91.87 |
484.71 |
30/4.14 |
19/2.48 |
28.96 |
|
Ruddy |
900 |
456.06 |
31.54 |
487.6 |
45/3.59 |
7/2.40 |
28.73 |
|
Canary |
900 |
456.06 |
59.1 |
515.16 |
54/3.28 |
7/3.28 |
29.52 |
|
Rail |
954 |
483.42 |
33.42 |
516.84 |
45/3.70 |
7/2.47 |
29.61 |
|
Catbird |
954 |
483.42 |
13.42 |
496. 84 |
36/4.14 |
1/4.14 |
28.95 |
|
Cardinal |
954 |
483.42 |
62.65 |
546. 07 |
54/3.38 |
7/3.38 |
30.42 |
|
Ortolan |
1033.5 |
523.68 |
36.19 |
559. 87 |
45/3.85 |
7/2.57 |
30.81 |
|
Tanager |
1033.5 |
523.68 |
14.51 |
538.19 |
36/4.30 |
1/4.30 |
30.12 |
|
Curlew |
1033.5 |
523.68 |
67.87 |
591.55 |
54/3.52 |
7/3.52 |
31.68 |
|
Bluejay |
1113 |
563.93 |
39.03 |
602.96 |
45/4.00 |
7/2.66 |
31.98 |
|
Finch. |
1113 |
563.93 |
71.55 |
635.48 |
54/3.65 |
19/2.19 |
32.85 |
|
Bunting |
1192.5 |
604.26 |
41.55 |
645.81 |
48/4.14 |
7/2.76 |
33.12 |
|
Grackle |
1192.5 |
604.26 |
76.58 |
680.84 |
54/3.77 |
19/2.27 |
33.97 |
|
Bittern |
1272 |
644.51 |
44.52 |
689.03 |
45/4.27 |
7/2.85 |
34.17 |
|
Pheasant |
1272 |
644.51 |
81.63 |
726.19 |
54/3.90 |
19/2.34 |
35.1 |
|
Skylark |
1272 |
644.51 |
17.87 |
662.38 |
36/4.78 |
1/4.78 |
33.42 |
|
Dipper |
1351.5 |
684.84 |
47.1 |
731.94 |
45/4.40 |
7/2.92 |
35.16 |
|
Martin |
1351.5 |
684.84 |
88.71 |
771.55 |
54/4.02 |
19/2.41 |
36.17 |
|
Bobolink |
1431 |
725.1 |
50.32 |
775.42 |
45/4.53 |
7/3.02 |
36.24 |
|
Plover |
1431 |
725.1 |
91.87 |
816.97 |
54/4.14 |
19/2.48 |
37.24 |
|
Nuthatch |
1510.5 |
765.35 |
52.9 |
818.25 |
45/4.65 |
7/3.10 |
37.2 |
|
Parrot |
1510.5 |
765.35 |
96.84 |
862.19 |
54/4.25 |
19/2.55 |
38.25 |
|
Lapwing |
1590 |
805.68 |
55.48 |
861.16 |
45/4.77 |
7/3.18 |
38.16 |
|
Falcon |
1590 |
805.68 |
102.1 |
907.81 |
54/4.36 |
19/2.62 |
39.26 |
|
Chukar |
1780 |
902.7 |
73.51 |
902.72 |
84/3.70 |
19/2.22 |
40.7 |
|
BlueBird |
2156 |
1092 |
88.8 |
1092.28 |
84/4.07 |
19/2.44 |
44.76 |
|
Kiwi |
2167 |
1100 |
47.5 |
1099.2 |
72/4.41 |
7/2.94 |
44.07 |
|
Thrasher |
2312 |
1170.8 |
65.15 |
1170.8 |
76/4.43 |
19/2.09 |
45.9 |
|
Grouse |
80 |
40.52 |
14.13 |
54.65 |
8/2.54 |
1/4.24 |
9.32 |
|
Petrel |
101.8 |
51.61 |
30.06 |
81.67 |
12/2.34 |
7/2.34 |
11.71 |
|
Minorca |
110.8 |
56.13 |
32.77 |
88.9 |
12/2.44 |
7/2.44 |
12.22 |
|
Leghorn |
134.6 |
68.19 |
39.81 |
108 |
12/2.69 |
7/2.69 |
13.46 |
|
Guinea |
159 |
80.58 |
46.97 |
127.55 |
12/2.92 |
7/2.92 |
14.63 |
|
Dotterel |
176.9 |
89.48 |
52.19 |
141.67 |
12/3.08 |
7/3.08 |
15.42 |
|
Dorking |
190.8 |
96.71 |
56.39 |
153.1 |
12/3.20 |
7/3.20 |
16.03 |
|
Brahma |
203.2 |
102.97 |
91.87 |
194.84 |
16/2.86 |
19/2.48 |
18.14 |
|
Cochin |
211.3 |
107.1 |
62.45 |
169.55 |
12/3.37 |
7/3.37 |
16.84 |
